Carburettor 28 KEIHIN PWK Flat slide

Carburettor 28 Keihin PWK original with flat slide.

If you are looking for the ideal carburettor for your small competition two-stroke, you have found it. The original 28 Keihin flat slide is easy to distinguish from all PWK-type replicas; the quality of materials such as the chrome on the bell, the screws, or the codes engraved on the body certify it.
The best option for your racing scooter or moped.
100% made in Japan.

 Dimensions:

• Outer diameter for manifold connection: 34mm
• Outer diameter for air filter connection: 48mm
• Carburettor body height: 123mm approx.
• Carburettor body width: 65mm approx.
• Intake distance (From intake mouth end to filter mouth end): 83mm

Original Carburettor setting:

• Main jet: 125 (PWK type)
• Low jet: 45 (PWK type)
• Slide needle: JH (5 positions, clip P3)
• Slide: 3.5

Remarks:

• Idle adjustment on the right side.
• Mixture adjustment on the left side.
• With depressor port.
