Yamaha MT-07 >2021 RX4 Koso multifunction marker

Yamaha [MT-07] Multifunction Koso marker >2021 RX4.

Features

Speedometer

• Display range: 0 ~ 360 km/h (0 ~ 225 MPH)
• Display unit: 1 km/h (MPH) Switchable

Odometer

• Display range: 0 ~ 999,999 km (mile) and then reset
• Display unit: 1 km (mile)

Tripmeter 1, 2

• Display range: 0.0~9,999.9 km (mile),
• can be reset manually.
• Adjustment unit: 0.1 km (mile)

Low fuel consumption

• Display range: 0 ~ 999 km (mile)
• Display unit: 1 km (mile)

Engine oil maintenance

• Adjustment range: User settings (500 ~ 16,000 km / 300 ~ 10,000 miles) ~ -999 km (mile)
• Automatically decreases according to the increase in total mileage.
• Display unit: 1 km (mile)
• Warning range: The texts turn red as a warning starting from 0 km (mile).

Maintenance mileage 1, 2

• Adjustment range: User settings (500 ~ 16,000 km/ 300 ~ 10,000 miles) ~ -999 km (miles),
• Automatically decreases according to the increase in total mileage.
• Display unit: 1 km (mile)
• Warning range: The texts turn red as a warning starting from 0 km (mile).

Maximum speed record

• Display range: 0 ~ 360 km/h (0 ~ 225 MPH)

Gear counter

• Display range: -, N, 1 ~ 6

Maximum gear record

• Display range: -, N, 1 ~ 6

Tachometer

• Display range: [MT-07]: 0 ~ 12,000 RPM
• [MT-09]: 0 ~ 13,000 RPM
• [XSR700]: 0 ~ 12,000 RPM
• [XSR900]: 0 ~ 13,000 RPM

Shift light warning

Display range: Continuous, intermittent, and intermittent BAR

• [MT-07]: 1,000 ~ 12,000 RPM
• [MT-09]: 1,000 ~ 13,000 RPM
• [XSR700]: 1,000 ~ 12,000 RPM
• [XSR900]: 1,000 ~ 13,000 RPM
• Adjustment unit: 1,000 RPM (Large grid),
• 500 RPM (Small grid)

Maximum rotation speed

• [MT-07]: 0 ~ 12,000 RPM
• [MT-09]: 0 ~ 13,000 RPM
• [XSR700]: 0 ~ 12,000 RPM
• [XSR900]: 0 ~ 13,000 RPM

Air temperature

• Display range: -10 ~ 100 ℃ (14 ~ 212 ℉)
• Display unit: 1 ℃ (℉)
• Warning range: LO means below -10 °C (14 °F);
• HI means above 100 °C (212 °F); the numbers will change to red and flash as a warning.

Coolant temperature

• Display range: 0 ~ 250 ℃ (32 ~ 482 ℉)
• Display unit: 1 ℃ (℉)

Maximum coolant temperature record

• Display range: 0 ~ 250 ℃ (32 ~ 482 ℉)

Coolant temperature warning

Display range: LO means below 39 °C (102 °F);

HI means above 117 °C (234 °F); the numbers will change to red and flash as a warning.

Unit change: You can switch to Celsius (°C) or Fahrenheit (°F).

Fuel gauge

• Display range: 6 levels
• Display unit: 1 level (16.6%)

Fuel warning setting

• Display range: The low fuel warning value will be 1 bar and below, the warning signal will flash as an alert.

Current fuel consumption

• Display range: 0 ~ 40.0 km/L, 2.5 ~ 99.9 L/100km, 0 ~ 99.9 MPG (US), 0 ~ 99.9 MPG (UK)
• Display unit: 0.1 km/L, 0.1 L/100km, 0.1 MPG (US), 0.1 MPG (UK)

Average fuel consumption

• Display range: 0 ~ 40.0 km/L, 2.5 ~ 99.9 L/100km, 0 ~ 99.9 MPG (US), 0 ~ 99.9 MPG (UK)
• Display unit: 0.1 km/L, 0.1 L/100km, 0.1 MPG (US), 0.1 MPG (UK)

Clock

• Adjustment range: 00:00 ~ 23:59 (24H), 1:00 ~ 12:59 (12H)

Trip time

• Display range: 0 ~ 999.9 hr
• Display unit: 0.1 hr
• Time 1, 2 (accumulated time)
• Display range: DC 8.0 ~ 18.0 V
• Display unit: DC 0.1 V

Voltmeter

• Display range: DC 8.0 ~ 18.0 V
• Indication unit: DC 0.1 V

Low voltage warning

• Adjustment range: DC 8.0 ~ 13.0 V,
• LO means the value is at or below the adjustment value; the numbers will turn red and flash as a warning.
• Adjustment unit: DC 0.1 V

High voltage alert

• Adjustment range: DC 13.1~18.0 V, HI means that the adjustment value is equal to or above. They will turn red and flash as a warning.
• Adjustment unit: DC 0.1 V

Target speed

• Adjustment range: 0 ~ 360 km/h (0 ~225 MPH)

Target distance

• Adjustment range: 50 ~ 1,500 m (1/32 ~ 30/32 Miles)

Maximum speed

• Speed: 0 ~ 360 km/h (0 ~ 225 MPH)
• Distance: 0 ~ 999 m (0~3,280 feet)

Rotation speed

• 0 ~ The rotation speed adjustment value

Display range

• Stable (connected), OFF (disconnected)
• iOS operating system: iOS 5.0 and above
• Android operating system: Android 9, Android 10
• Phone Battery
• Display range: 3 bars
• Incoming call alert
• Display range: Shows the name or number up to
• 12 Chinese characters; "..." is displayed for more than
• 12 characters; "Unknown" is displayed when there is no name.
• iOS - Show the name or the number of the incoming call
• Android - Shows the number
• Incoming call notification online
• Display range: Show name up to 12 Chinese characters
• Chinese characters; "..." is displayed for more than 12 characters;
• "Unknown" is displayed when there is no name
• Supports LINE, WeChat, WhatsApp
• Supports iOS, not Android
• Music playback message
• Music name: 15 Chinese characters, and "..." is displayed
• for more than 15 characters
• Singer name: 18 Chinese characters, and "..." is displayed
• more than 18 characters
• Total music duration: 00:00 ~ 9:59:59, and "9:59:59"
• is displayed for more than 9:59:59
• Supports iOS, not Android.
• Current playback time: 00:00 ~ 9:59:59, and "9:59:59" for more than 9:59:59I
