Spark plug fixed terminal NGK BR10ES / 4684 - Suppressor cap

NGK BR10ES 4684 heat range 10 Spark plug with fixed terminal for motorcycle and scooter

The NGK BR10ES Spark plug, with reference 4684, belongs to NGK's Standard range and is designed to provide reliable ignition and proper heat dissipation in compatible engines. Its heat range 10 corresponds to a cold Spark plug, intended for engines and setups that operate at high temperatures.

It incorporates a center electrode with copper core, which promotes heat dissipation and helps maintain proper operating conditions. Its electrode features a conventional construction with a nickel tip and a single ground electrode.

The NGK BR10ES also incorporates a 5 kΩ suppressor resistance, which helps reduce electromagnetic interference generated by the ignition system. It features an alumina silicate ceramic insulator, designed to withstand the thermal and electrical demands of engine operation.

This version includes a fixed upper terminal, so it does not have a removable nut. It is important to check that the Spark plug cap is compatible with this type of connection before installation.

Key features

• NGK Spark plug from the Standard range.
• Manufacturer reference: BR10ES / 4684.
• Heat range 10, cold configuration.
• Center electrode with copper core.
• Conventional ground electrode with nickel tip.

• Alumina silicate ceramic insulator.
• Designed for compatible 2-Stroke and 4-stroke engines.

Technical specifications

• Thread diameter: 14 mm.
• Thread pitch: 1.25 mm.
• Thread length: 19 mm.
• Wrench size: 20.8 mm.
• Terminal type: fixed, non-removable.
• Suppressor resistance: 5 kΩ.
• Electrode gap: 0.8 mm (reference value).

Application and recommended use

The NGK BR10ES is intended for engines that specifically require a heat range 10 Spark plug. It is an option for certain sport setups and engines that operate at high temperatures, provided that this heat range and its dimensions match the manufacturer's specifications.

Compatible models

DERBI

• GP1 50 LC 2002-2004
• GP1 50 LC Open 2007-2011
• GP1 50 V1 LC 2005-2006
• GP1 50 V2 LC 2005-2007

GILERA

• DNA 50 GP Experience 2003-2008

KAWASAKI

• KR-1R 250 1989
• KR-1S 250 1989-1992

PIAGGIO

• NRG 50 LC DD MC2 Extreme 2000-2001
• NRG 50 LC DD MC3 2001-2006
• NRG 50 LC DD MC3 Purejet 2002-2004
• Zip 50 2-Stroke LC SP 2012-2015

SUZUKI

• RM 80 2000-2001
• RM 80 X 1997-1999
• RM 85 2002-2013
• RM 85 L 2003-2020
